RTS Serious Stall Converters

RTS high stall torque converters are designed for serious-minded performance enthusiasts and offer additional strength and durability. The higher stall speeds of these converters will launch the car in a higher RPM range where more torque is readily available, resulting in quicker acceleration. They’re available for a variety of transmission makes and models. They are also available in a custom build model to suit any performance high horsepower application.

Features

  • Built using state-of-the-art tools & equipment
  • Includes NEW components
  • Billet hub
  • Welded fins on turbine and impeller
  • Welded pilot
  • Chromoly Flanged hub, acts as a internal Anti Balloon plate
  • All critical surfaces are resurfaced by skilled craftsman
  • Pressure tested to ensure a full and complete weld
  • Electronically balanced for precision accuracy
  • Made in the USA!

Torque Converter Specs

Stall: 2200-2500
Series: Bandit Plus rate up to 650hp
Transmission Type: C4 26 spline
Size: 10"
Turbine: 26 spline
Bolt Circle: 10.5

Flexplate: Accepts 157 Tooth ( May need to open Flexplate holes for larger Bolts)
Pilot Size: 1.375"
Mount: 4 Studs, 7/16x24
